Bigtreetech Pi TFT43 V2.1 – 4.3″ Capacitive Touchscreen for Raspberry Pi & 3D Printing

The BIGTREETECH Pi TFT43 V2.1 is a sleek and powerful 4.3-inch LCD capacitive touchscreen designed to bring intuitive control and vibrant visuals to your Raspberry Pi projects and 3D printing setups. With its 800×480 resolution and responsive 5-point touch capability, this display delivers crisp graphics and smooth interaction, making it ideal for Klipper Screen, OctoPrint, and other Raspberry Pi-based interfaces.

Key Features

• High-Resolution Display: 4.3-inch LCD with 800×480 resolution for sharp, clear visuals.
• Capacitive Multi-Touch: Supports 5-point touch for precise and responsive input.
• DSI Interface: Directly driven by the Raspberry Pi’s DSI port, ensuring seamless integration without extra drivers.
• Plug & Play Design: Powered directly by the Raspberry Pi, eliminating the need for external power supplies.
• Compact & Practical: Display area of 95.0 × 53.85 mm, perfect for compact builds.
• Easy Mounting: Unique rear mounting holes allow direct installation of Raspberry Pi boards for a neat, space-saving setup.
• Adjustable Brightness: Fine-tune screen brightness to suit your environment and workflow.
• Klipper Screen Compatible: Optimized for 3D printing control interfaces, giving you real-time monitoring and adjustments.

Applications

• 3D Printer Control: Pair with Klipper or OctoPrint for a streamlined touchscreen interface.
• DIY Raspberry Pi Projects: Ideal for dashboards, smart home displays, and embedded systems.
• Compact Workstations: Perfect for makers who want a small, efficient, and responsive display solution.

Technical Specifications

• Screen Size: 4.3 inches
• Resolution: 800 x 480
• Touch Type: Capacitive, 5-point
• Display Area: 95.0 x 53.85mm
• Interface: DSI (direct Raspberry Pi interface)
• Power Supply: Raspberry Pi powered
• Compatibility: Raspberry Pi, Klipper Screen

Why Choose the Pi TFT43 V2.1?

The BIGTREETECH Pi TFT43 V2.1 combines performance, simplicity, and versatility. Whether you’re upgrading your 3D printer interface or building a custom Raspberry Pi project, this touchscreen offers a plug-and-play solution with professional-grade responsiveness.

Please note: Pi TFT screens are specially designed for Raspberry Pi, which has a DSI port to connect to Raspberry Pi, and it is also compatible with Bigtreetech Pi 2.
