Linneoflon FEP Wire

Linneoflon FEP Wire

0.25mm2, 0.5mm2 and 0.75mm2 FEP wire designed and specified by Linneo.

Suitable for wiring up all low voltage, high-temperature connections in drag chains of your Voron printer.

The high-quality but lower cost alternative to Heluflon wire.

Technical data:

• tinned copper conductors
• 0.25mm2: 40 strands, 0.5mm2: 37 strands, 0.75mm2: 37 strands
• insulation material: FEP
• 0.25mm2: 1.0mm outer diameter, 0.5mm2: 1.4mm outer diameter, 0.75mm2: 1.6mm outer diameter
• temperature rating: -90 to 205°C
• minimum bending radius: 0.25mm2: 5mm (5x wire diameter), 0.5mm2: 5.6mm (4x wire diameter), 0.75mm2: 6.4mm (4x wire diameter)
