GDStime GDA6020 DC 24V Volt 60x60x20mm Axial Brushless Fan

GDStime GDA6020 DC 24V Volt 60x60x20mm Axial Brushless Fan

Quick Details
Type: FAN
Heatsink Material: Plastic
Fan Life: 50000 Hrs
Power: 1.56W
Noise: 26dba
Fan Size: 60x60x20mm
Bearing: dual ball bearing
Power Interface: 2PIN
Fan Speed Control: 5000rpm
Model Number: GDA6020

Product Description:
Waterproof: IP45-68
Rated Voltage: DC24V (14 – 26V)
Rated Current:0.12A
Bearing: Dual Ball Bearing
Fan Speed: 5000 RPM±10%
Noise Level: 35.6dBA±10%
Air Flow: 28CFM (0.26 In H2O)
Weight:38g
Fan size:60x60x20mm

Features:

Motor Protection

• RP: Reverse Protection
• SS: Soft Start
• AS: Auto Restart
• CL: Current Limit

Singal output

•  FG: Frequency Generator
•  RHD(RD): Rotation Detection(High)
•  RDL: Rotation Detection(Low)
•  LD: Low Detection

Speed control mode

•  PWM: Pulse Wide Modulation
•  TC: Temperature Control
•  VC: Voltage Control
•  RC: Resistor Control
•  SC: Const Speed
