LDO Nitehawk Hexa 6 + 1 USB Hub

LDO Nitehawk Hexa 6 + 1 USB Hub – High-Performance USB Hub for Multi-Toolhead Systems

The LDO Nitehawk Hexa is a 6+1 port USB hub adapter designed for multi-toolhead 3D printers, providing a clean and efficient solution for managing power and communication across multiple toolboards. By integrating six Nitehawk USB adapters, a USB 2.0 hub, and a 24V power splitter into a single compact PCB, the Nitehawk Hexa simplifies wiring while ensuring stable, high-current power delivery.

Key Features:

• Efficient Wiring: Uses a single 24V power cable and a USB-C upstream connection to handle power and data for up to six downstream toolboards.
• Plug-and-Play Functionality: Operates like a standard USB hub, requiring no additional software, drivers, or configuration.
• High-Current Capability: Supports up to 30A, making it ideal for demanding setups with multiple heated toolheads.
• Dedicated Power Protection: Each downstream port includes data line protection and a replaceable fuse, ensuring safe operation.
• Auxiliary USB-A Port: Allows users to connect additional USB devices, such as webcams, flash drives, or Arduino boards.

Performance & Applications:

The Nitehawk Hexa is the ideal solution for multi-toolhead 3D printers, such as IDEX or stealth changer systems, where efficient power distribution and reliable communication are critical. Its robust design ensures stable operation, reducing wiring complexity while maintaining high-speed data transfer.

By offering streamlined connectivity and advanced power management, the LDO Nitehawk Hexa USB 6 +1 USB hub is a must-have upgrade for users seeking optimized multi-toolhead performance.

More information here
