LDO Toolhead Break-out Board

US$6.41US$30.11

The LDO Toolhead breakout board facilitates the wiring of your Stealthburner or Afterburner toolhead PCBs.

Add to Cart
LDO Toolhead Break-out Board
LDO Toolhead Break-out Board
US$6.41US$30.11

LDO Toolhead Break-out Board

The LDO Toolhead breakout board facilitates the wiring of your Stealthburner or Afterburner toolhead PCBs.

The LDO Voron Kits (Switchwire, V2.4r2, Trident) all come with a version of the Afterburner Toolhead Board and a wiring harness for 300 (1.9m long) or 350mm (2.1m long) build sizes.

Stealthburner PCB compatibility:

The Stealthburner board will work with the LDO wiring harness with minimum of 1 change on the breakout board. The wire that is connected to the CT header, the black wire should be removed as its no longer needed and the White wire should go to a 5v source. The easiest way is to set the last always on fan to 5v and connect it there, you can see in the diagram below the jumper (Blue) is on the 5v setting and the wire is going to the positive pin.

Here

More info on the LDO website.

Additional information

Weight0.04 kg
Dimensions10 × 10 × 2.5 cm
Size

no harness, 250mm², 300mm², 350mm²

Brand

LDO
